Programming 4-11
1560D-UM051D-EN-P – February 2005
Basic Setup The Basic Setup programming group provides a limited parameter set,
allowing quick start-up with minimal adjustments. If the user is planning
to implement some of the advanced features (i.e., Dual Ramp, Unbalance
Level, etc.), then the Advanced Setup programming group should be
selected. It provides all the Basic Setup parameter set plus the advanced set.
Parameter Option
SMC Option
Displays the type of controller. This is factory set and not
adjustable.
Standard
Starting Mode
Allows the user to program the SMC Dialog Plus controller
for the type of starting that best fits the application.
Soft Start, Current Limit
Ramp Time #1
This sets the time period during which the controller will
ramp the output voltage.
0 to 30 seconds
Initial Torque #1 X
The initial reduced voltage output level for the voltage ramp
is established and adjusted with this parameter.
0 to 90% locked rotor torque
Current Limit Level Y
This parameter provides adjustability for the reduced output
voltage level provided to the motor.
50 to 600% full load current
Kickstart Time
A boost of 550% of full load current is provided to the motor
for the programmed time period.
0.0 to 2.0 seconds
Stall Delay
Allows the user to program the stall protection delay time.
The delay time begins after the start time has timed out.
0.0 to 10.0 seconds
Energy Saver
Off (not used in MV Dialog
Plus)
Aux. Contacts 1 & 2
Form C contacts are provided as standard with the SMC
Dialog Plus controller. These contacts are located at
terminals 18, 19 and 20. Aux. Contacts 1 & 2 allow the user
to configure the operation of the contacts.
Normal, Up-to-Speed
Aux. Contact 3
A third auxiliary contact is provided between terminals 29
and 30. Aux. Contact 3 allows the user to program the
operation of the contact.
Normal, Fault
Contact 3 Config
This parameter provides the user with the ability to program
the “powered up” state of the third auxiliary contact.
N.O., N.C.
Parameter Mgmt Z
The newly programmed parameter values can be saved to
memory, or the factory default parameter values can be
recalled.
Ready, Default Init., Recll
Frm EE, Store in EE
X Starting Mode must be programmed to Soft Start to obtain access to the Initial Torque parameter.
Y Starting Mode must be programmed to Current Limit to obtain access to the Current Limit Level parameter.
Z The new programmed parameter values will not be stored to the EEPROM without the user’s direction
in Parameter Management. Store in EE.
