4-4 Programming
1560D-UM051D-EN-P – February 2005
Programming Menu (cont.) Table 4.A
Parameter Linear List
Parameter No. Description Parameter No. Description
1 Volts Phase A-B 45 Slow Speed Dir.
2 Volts Phase B-C 46 Slow Accel Current
3 Volts Phase C-A 47 Slow Running Current
4 Current Phase A 48 Braking Current
5 Current Phase B 49 Factory Use
6 Current Phase C 50 Factory Use
7 Wattmeter (MW) Y 51 Stopping Current
8 Megawatt Hours Y 52 Undervolt. Level
9 Elapsed Time 53 Undervolt. Delay
10 Power Factor Y 54 Undervolt. Level
11 Mtr. Therm Usage 55 Undervolt. Delay
12 Factory Use (MV Ratio) 56 Jam Level
13 Factory Use 57 Jam Delay
14 SMC Option 58 Unbalance Level
15 ETM Reset 59 Rebalance X
16 Factory Use 60 Underload Level
17 Parameter Mgmt. 61 Underload Delay
18 Clear Fault 62 Phase Reversal
19 Fault Buffer #1 63 Starts per Hour
20 Fault Buffer #2 64 Restart Attempts
21 Fault Buffer #3 65 Restart Delay
22 Fault Buffer #4 66 Factory Use
23 Fault Buffer #5 67 Factory Use
24 Factory Use 68 Factory Use
25 Factory Use 69 Line Voltage
26 Factory Use 70 Motor FLC
27 Factory Use 71 Factory Use
28 Starting Mode 72 Mtr. Code Letter
29 Dual Ramp 73 Factory Use
30 Ramp Time #1 74 Converter Rating
31 Initial Torque #1 75 CT Ratio
32 Ramp Time #2 76 Calibration
33 Initial Torque #2 77 Enter Calib. Amps
34 Current Limit Level 78 Language Select
35 Kickstart Time 79 Motor HP Rating
36 Overload Class 80 Motor kW Rating
37 Stall Delay 81 LRC Ratio
38 Energy Saver X 82 Factory Use
39 Aux. Contacts #1 and #2 83 Factory Use
40 Aux. Contact #3 84 Service Factor
41 Contact 3 Config. 85 Logic Mask
42 Stop Time 86 Unbalance Delay
43 Factory Use 84 S/W Version
44 Slow Speed Sel. 88 Overload Reset
X Not used with MV Dialog Plus Controller.
Y Available with the following (or newer) MV Dialog Plus firmware versions:
– Standard Module 1.11L
– Soft Stop 1A11L
– Pump Control 1B09L
Power Factor is arbitrarily fixed at 0.85 during bypass.
