Troubleshooting 10-17
1560D-UM051D-EN-P – February 2005
Figure 10.1 – Low Voltage Panel & Power Cell Detail (1562D) • 180/360A, 2400 V to 4160 V
Bulletin 1562D, phase A module shown extracted from cabinet.
Low voltage panel can swing out for access to Phase A module.
Important: For 1503D, refer to OEM documentation for
location of printed circuit boards and power stacks.
Voltage
Feedback
Board
Voltage
Feedback
Board
