Specifications and Dimensions Appendix A
Environmental Specifications
AC Line Filter Specifications
Line filters compatible with a Kinetix 7000 drive sourcing input power from an
AC power supply are listed below.
Line filters compatible with a Kinetix 7000 drive sourcing input power from a
regenerative DC bus with a 8720MC-RPS unit are listed below.
Attribute Operational Range Storage Range (nonoperating)
Temperature, ambient 0…50 C (32…122 F) -40…+70 C (-40…+158F)
Relative humidity 5…95% noncondensing 5…95% noncondensing
Altitude
1000 m (3281 ft)
3000 m (9843 ft) with derating
3000 m (9843 ft) during transport
Vibration
5…55 Hz @ 0.35 mm (0.014 in.) double amplitude, continuous displacement; 55…500 Hz @ 2.0 g peak constant acceleration (10 sweeps in
each of 3 mutually perpendicular directions).
Shock 15 g, 11 ms half-sine pulse (3 pulses in each direction of 3 mutually perpendicular directions)
Kinetix 7000 Drive
Cat. No.
AC Line Filter
Cat. No.
2099-BM06-S
2090- XXLF-TC350
2099-BM07-S
2099-BM08-S 2090- XXLF-TC365
2099-BM09-S 2090- XXLF-TC3100
2099-BM10-S 2090- XXLF-TC3150
2099-BM11-S 2090- XXLF-TC3200
2099-BM12-S 2090- XXLF-TC3250
8720MC-RPS
Cat. No.
AC Line Filter
Manufacturer and Cat. No.
8720MC-RPS065BM-HV2 Schaffner: FN3100-80-35
Soshin Electric: HF3080C-TOA
8720MC-RPS190BM 8720MC-EF190-VB
