Chapter 1 Start
CE and UK Requirements - System with LIM
To meet CE and UK requirements when your Kinetix 7000 system includes the
line interface module (LIM), follow all the requirements as stated in CE and UK
Requirements - System without LIM on page 17
and these additional
requirements that also apply to the AC line filter:
• Install the LIM, 2094-XL75S-Cx or 2094-BL50/75S, and line filter
(2090-XXLF-TCxxx) as close to the Kinetix 7000 drive as possible.
CE and UK Requirements - System with DC Common Bus Through
8720MC-RPS
To meet CE and UK requirements when your Kinetix 7000 system includes a
common DC bus with an 8720MC-RPS, follow all the requirements as stated in
the CE and UK Requirements - System without LIM on page 17
, the
recommended installation and wiring in the 8720MC Regenerative Power
Supply Reference Manual, publication 8720MC-RM001
, and these additional
requirements:
• Install a three-phase line filter on the AC input power line of the RPS as
indicated in Interconnect Diagrams beginning on page 161
.
• Install a single-phase line filter when attaching an AC line input to the
RPS MC1/2 circuit as indicated in the Interconnect Diagrams beginning
on page 161
.
The full rated current on the AC input line should not exceed that of the line
interface module.
Catalog numbers 2094-XL75S-Cx or 2094-BL50S for 2099-BM06-S and
2099-BM07-S Kinetix 7000 drives, or 2094-BL75S for 2099-BM08-S Kinetix
7000 drives.
CE and UK require use of a grounded secondary or source with a 2099-
BMxx-S drive.
Never use a LIM in an ungrounded input, due to the potential for high line-
to-neutral voltages damaging components within the line filter.
