Rockwell Automation Allen-Bradley Kinetix 7000 User Manual

158 Rockwell Automation Publication 2099-UM001G-EN-P - December 2022
Appendix A Specifications and Dimensions
Product Dimensions
This section provides a quick reference table to common dimensions for Kinetix
7000 drives (height, width, depth, and mounting hole locations), and outline
drawings with dimensions related to the specific frame sizes.
Figure 70 - 2099-BM06-S 2099-BM07-S, and 2099-BM08-S Approximate Dimensions
224.3
(8.82)
7.0
(0.28)
31.9
(1.26)
517.5
(20.37)
495.0
(19.49)
254.12
(10.00)
192
(7.56)
15.27
(0.60)
7.0
(0.28)
8.0
(0.31)
Ø 7.0
(0.28) X2
66.0
(2.60)
97.0
(3.82)
137.2
(5.40)
187.0
(7.36)
31.9
(1.26)
151.1
(5.95)
165.1
(6.50)
160.1
(6.30)
165.9
(
6.53)
Ø 37.3
(1.47) X2
Ø 22.4
(0.88)
Ø 28.7
(1.13)
66.0
(2.60)
130.0
(5.19)
186.0
(7.32)
31.9
(1.26)
Ø 28.7
(1.13)
Ø 47.0
(1.85) 2
X
Ø 34.9
(1.37) 2X
165.9
(6.53)
165.1
(6.50)
160.1
(6.30)
Dimensions are in millimeters (inches)
Important: Additional clearance below the connector is
necessary to provide the recommended cable bend radius.
Bottom View
(2099-BM06-S and 2099-BM07-S)
Bottom View
(2099-BM08-S)
