88 Rockwell Automation Publication 2099-UM001G-EN-P - December 2022
Chapter 4 Connect the Kinetix 7000 Drive System
Wire AC Input Power
Wire 460V AC input power to your Kinetix 7000 drive as described in Ta b l e 3 7.
See Power Terminal Block (PTB) Connections for more information.
Table 37 - AC Input Power Connections
Wire DC Input Power (Common Bus Configurations Only)
Wire the DC input power from a leader regenerative power supply (8720MC-
RPS) to a Kinetix 7000 drive as described in Tab le 3 8
. See Power Terminal Block
(PTB) Connections on page 49
for more information.
Kinetix 7000
Drive Cat. No.
Signal Terminal Recommended Wire Size
mm
2
(AWG)
Torque
N•m (lb•in)
2099-BM06-S
2099-BM07-S
2099-BM08-S
L1
L2
L3
Ground
R
S
T
PE
25…2.5 (3…14) 1.8 (16)
2099-BM09-S L1
L2
L3
R
S
T
50…4 (1/0…12) 3.6 (32)
Ground PE 50…4 (1/0…12) 5 (44)
2099-BM10-S L1
L2
L3
R
S
T
70…10 (2/0…8) 15 (133)
Ground PE 50…4 (1/0…12) 5 (44)
2099-BM11-S
2099-BM12-S
L1
L2
L3
R
S
T
100…10 (4/0…8) 12 (104)
Ground PE 50…4 (1/0…12) 5 (44)
DC power from the regenerative power supply (8720MC-RPS) is typically
routed to a power distribution box. Fusing will be placed before and after
the distribution box, providing protection for both the 8720MC-RPS and
Kinetix 7000 drive.
