39. From the Bus Regulator Configuration pull-down menu, choose the
component appropriate for your actual hardware configuration. Note: The
Kinetix 7000 drive internal dynamic brake IGBT is not utilized by the
drive main control for bus regulation therefore any type of regulation must
come from an external source.
40. Click OK.
41. Repeat steps 1…27 for each additional axis.
42. Verify your Logix program and save the file.
Download the Program
After completing the Logix configuration, you must download your program to
the Logix processor.
If your drive requires Then choose
No bus regulator configuration <none>
External Shunt configuration 1336-MOD-KB005, KB010 or KB050
1336-WB009, WB035 or WB110
(1)
(1) External shunt configuration 1336 MOD-KBxxx and 1336-WBxxx are no longer available for new sale but are selectable as
of this manual release.
External regeneration power supply 8720MC-RPS027, 8720MC-RPS065, or 8720MC-RPS190
(2)(3)(4)
(2) 8720MC-RPSxxx is an external regenerative converter system used to regulate the DC bus that is connected to the Kinetix
7000 drive. Selecting this device requires the Kinetix 7000 drive GPIO terminal block pins 7 and 8 to be wired. See
Figure 75 on page 165
for an example.
(3) 8720MC-RPS027BM-HV1 is no longer available for sale.
(4) 8720MC-RPS065BM-HV1 has been superseded by 8720MC-RPS065BM-HV2.
