Appendix A Specifications and Dimensions
AC Line Reactors
380…480V, 50/60 Hz, three-phase, line reactors compatible with a Kinetix 7000
drive connected to a three-phase, AC input power source are listed below.
Table 66 - Compatible Kinetix 7000 Drives and AC Line Reactors
Line reactors compatible with a 8720MC-RPS Regenerative Power Supply
sourcing input power from an AC power supply are listed below. They must be
configured as shown in the Regenerative Power Supply example on page 169
.
Table 67 - Compatible Kinetix 7000 Drives, 8720MC-RPS Regenerative Power Supplies and
8720MC Line Reactors
Kinetix 7000 Drive
Cat. No.
3% Impedance Input Line Reactor
(1)
5% Impedance Input Line Reactor
(1)
IP00 (Open Style)
Cat. No.
IP11 (NEMA/UL Type 1)
Cat. No.
IP00 (Open Style)
Cat. No.
IP11 (NEMA/UL Type 1)
Cat. No.
2099-BM06-S 1321-3R45-B 1321-3RA45-B 1321-3R45-C 1321-3RA45-C
2099-BM07-S 1321-3R55-B 1321-3RA55-B 1321-3R55-C 1321-3RA55-C
2099-BM08-S 1321-3R80-B 1321-3RA80-B 1321-3R80-C 1321-3RA80-C
2099-BM09-S 1321-3R100-B 1321-3RA100-B 1321-3R100-C 1321-3RA100-C
2099-BM10-S 1321-3R130-B 1321-3RA130-B 1321-3R130-C 1321-3RA130-C
2099-BM11-S 1321-3R200-B 1321-3RA200-B 1321-3R200-C 1321-3RA200-C
2099-BM12-S 1321-3RB250-B 1321-3RAB250-B 1321-3RB250-C 1321-3RAB250-C
(1) Input line reactors were sized based on the NEC fundamental motor amps.
Kinetix 7000 Drive
Cat. No.
8720MC-RPS Regenerative Power
Supply Cat. No.
(1)
(1) Regenerative Power Supply (RPS) selection is for a single motor/drive combination. When combining multiple drives on the same
RPS module, the selection will change.
8720MC Line Reactor
Cat. No.
2099-BM07-S 8720MC-RPS065BM 8720MC-LR05-048B
2099-BM08-S
2099-BM09-S 8720MC-LR10-062B
8720MC-RPS065BM and
8720MC-RPS065BS
8720MC-LR05-048B
(requires two units, one for the master
RPS unit and one for the slave RPS unit.)
2099-BM11-S 8720MC-LR10-062B
(requires two units, one for the master
RPS unit and one for the slave RPS unit.)
8720MC-RPS190BM 8720MC-LR10-100B (required two units)
2099-BM12-S
