Preface
Summary of Changes
This manual contains new and updated information. Changes throughout this
revision are marked by change bars, as shown to the right of this paragraph.
This table contains the changes made to this revision.
About This Publication
This manual provides detailed installation instructions for mounting, wiring, and
troubleshooting your Kinetix® 7000 drive, and system integration for your drive/
motor combination with a Logix controller.
Who Should Use This Manual
This manual is intended for engineers or technicians directly involved in the
installation and wiring of the Kinetix 7000 drive, and programmers directly
involved in the operation, field maintenance, and integration of the Kinetix 7000
drive with a Sercos interface module.
If you do not have a basic understanding of the Kinetix 7000 drive, contact your
local Rockwell Automation sales representative before using this product for the
availability of training courses.
Conventions Used in This
Manual
These conventions are used throughout this manual.
• Bulleted lists such as this one provide information, not procedural steps.
• Numbered lists provide sequential steps or hierarchical information.
Additional Resources
The following documents contain additional information concerning related
products from Rockwell Automation. You can view or download publications at
rok.auto/literature
.
Topic Page
Added “and UK” after CE, where applicable Throughout
Added UK and UKCA mark information to Agency Compliance section 16
Updated UKCA Agency Certification 154
Resource Description
Kinetix 7000 DC-DC Converter and Control Board Kits, publication 2099-IN002
Provides information on removing and replacing the DC-DC converter, DC-DC converter
fuse, and the control board assembly in a Kinetix 7000 drive.
Kinetix 7000 Drive Installation Instructions, publication 2099-IN003 Provides information on installing a Kinetix 7000 drive.
Fiber-optic Cable Installation and Handling Instructions, publication 2090-IN010 Provides information on proper handling, installing, testing, and troubleshooting fiber-
optic cables.
ControlLogix® Sercos interface Module Installation Instructions, publication 1756-IN572
Provides details about installing a 3, 8, or 16-Axis ControlLogix Sercos interface module.
