Specifications and Dimensions Appendix A
External Shunt Modules
Refer to this table for active shunt solutions for use with Kinetix 7000 drives from
Rockwell Automation Encompass® partners.
Precharge Capacities of the
Regenerative Power Supply
Internal (built-in) and external precharge capacities of the regenerative power
supply (RPS) are listed below.
Rockwell Automation Encompass Partner Contact Information
Powerohm Resistors, Inc. 5713 13th Street
Katy, TX 77493
Tel: (800) 838-4694
http://www.powerohm.com
Bonitron, Inc. 521 Fairground Court,
Nashville, TN 37211
Tel: (615) 244-2825
http://www.bonitron.com
Attribute 8720MC-RPS065Bx-HV2 8720MC-RPS190Bx
Rated Output kVa (750V DC bus)
(1)
(1) For 8720MC-RPS065-HV2 and 8720MC-RPS190, you may have up to two slave units with a master unit. Multiply these values by the
number of slave units.
45 133
DC Amperes Continuous
(1)
64 190
DC Amperes Peak (1 minute)
(1)
96 285
Built-in Capacitor 1900 µF 7600 µF
Built-in Resistor (Resistance/W) 7000 µF (22 Ohms/120 W) 25000 µF (10 Ohms/400 W)
External Resistor (Min Resistance)
(2)
(3)
(2) Use this case only when the bus capacitance exceeds the internal precharge rating. You must use the specified resistor. Calculate
rated wattage and surge resistivity for that resistor. See the 8720MC Regenerative Power Supply Installation Manual, publication
8720MC-RM001
, for configuration details.
(3) Use this case only when the bus capacitance exceeds the external resistor rating. You must use the specified resistor. Calculate rated
wattage and surge resistivity for that resistor. See the 8720MC Regenerative Power Supply Installation Manual, publication 8720MC-
RM001, for configuration details.
110000 µF (20 Ohms) 165000 µF (10 Ohms)
External Circuit (Min Resistance)
(3)
220000 µF (4.7 Ohms) 495000 µF (1.5 Ohms)
Large levels of load capacitance may require modification of the 8720
regenerative power supply internal precharge/discharge circuit.
See the Wiring instructions in the 8720MC Regenerative Power Supply
Installation Manual, publication 8720MC-RM001
, for information on how
to determine the appropriate precharge/discharge resistance power value
(Ohms/Watt) to accommodate the capacitance of your system.
