Rockwell Automation Publication 2099-UM001G-EN-P - December 2022 161
Appendix B
Interconnect Diagrams
This appendix provides wiring examples and system block diagrams to assist you
in wiring your Kinetix® 7000 system components.
Topic Page
Interconnect Diagram Notes 162
Figure 73 Kinetix 7000 Drive AC Power Wiring 163
Figure 74
Kinetix 7000 Drive AC Powered with a 8720MC-RPS065BM Regenerative Power Supply 164
Figure 75 8720MC-RPS065BM Regenerative Power Supply to a Single Kinetix 7000 Drive 165
Figure 76 8720MC-RPS065BM Regenerative Power Supply to Multiple Kinetix 7000 Drives 166
Figure 77
Dual 8720MC-RPS065Bx Regenerative Power Supplies to a Single Kinetix 7000 Drive 167
Figure 78 Kinetix 7000 Drive AC Powered with a 8720MC-RPS190BM Regenerative Power Supply 168
Figure 79 8720MC-RPS190BM Regenerative Power Supply to a Single Kinetix 7000 Drive 169
Figure 80
8720MC-RPS190BM Regenerative Power Supply to Multiple Kinetix 7000 Drives 170
Figure 81 Dual 8720MC-RPS190Bx Regenerative Power Supplies to a Single Kinetix 7000 Drive 171
Figure 82 Kinetix MPL Motors (Bayonet Style Connector) 172
Figure 84
Kinetix MPL and MPM Motors (Circular DIN Style Connector) 174
Figure 85 Kinetix HPK Motors 175
Figure 87 Kinetix MMA Motors 177
Figure 89
Kinetix RDB Motors 181
Figure 90 Kinetix Safe Torque Off Feature Block Diagram 182
