Rockwell Automation ArmorStart Bulletin 280G - Page 41

Installation and Wiring 2-23
Figure 2.19 Bulletin 284G Safety ArmorStart
Motor
Connection
DeviceNet
Connection
(Mini/M18)
Local Disconnect
6 Inputs
(Micro/M12)
Dynamic Brake
3-Phase Power
Receptacle
LED Status
Indication
A1/A2
Control Power
SM
Control Brake
