15
Expanding the memory
Expanding the memory
How to expand the memory
1. Turn off the power to the CDX-1 and any connected equipment, and then
disconnect all cables attached to the CDX-1.
2. Turn the CDX-1 upside-down, and remove the expanding memory cover.
fig.12-02a
fig.12-03
3. Press outward the white clips at either
end of the socket should be in the
downward position.
fig.12-02
4. Paying attention to the location of the
notch on the memory module and the
orientation, insert it vertically within the
guides at either side of the socket.
fig.12-04
5. Move the white clips upward, and press
them until the memory module is locked
in place.
6. Return the CDX-1’s top cover to its original position.
When turning the unit upside-
down, get a bunch of
newspapers or magazines, and
place them under the four
corners or at both ends to
prevent damage to the buttons
and controls. Also, you should
try to orient the unit so no
uttons or controls get
damaged.
screws to be removed (two)
the expanding memory cover
If you have difficulty inserting
the memory module, try tilting
it a bit and inserting one end at
a time.
