158
Using the CDX-1 with other MIDI devices
Using an external MIDI sound module
to play the rhythm guide
The rhythm guide can be played using your favorite sounds on another MIDI device.
1. Use a MIDI cable to connect the CDX-1 and your MIDI sound module as shown
in the diagram.
fig.5-32e
2. Press [UTILITY].
The Menu are displayed as icon.
fig.5-24
3. Press CURSOR [ ] to select the MIDI
icon.
4. Press [YES/ENTER].
The MIDI settings screen appears.
fig.5-25
5. Press CURSOR [ ] to move the cursor to
“Rhythm ch” line.
6. Turn the TIME/VALUE dial to set the MIDI channel (1–16).
If you select “OFF,” note messages of the rhythm guide will not be transmitted.
7. Press [DISPLAY] to return to the Basic screen.
How the rhythm guide sounds correspond to note numbers
fig.5-33e
If your external MIDI sound module is GS- or GM-compatible, you can use it
without further settings. If it is not compatible with either of these, you will need to
make settings on your external MIDI sound module to change the sounds that
correspond to each note number. For details on making these settings, refer to the
manual of your MIDI sound module.
“Using the rhythm guide”
(p. 116)
MIDI OUTMIDI IN
CDX-1
MIDI Sound Module
If you are using an external
MIDI sound module to play
the rhythm guide, use the
controls of the external MIDI
sound module to adjust the
volume level.
Rhythm guide sound Note number
Metronome (click: low tone) A 1 (33)
Metronome (click: high tone) A#1 (34)
Kick C 2 (36)
Stick C#2 (37)
Snare D 2 (38)
Hand Clap D#2 (39)
Closed hi-hat F#2 (42)
Half open hi-hat G#2 (44)
Open hi-hat A#2 (46)
