154
Using the CDX-1 with other MIDI devices
Synchronized playback with the CDX-1
as the master
The CDX-1 can operate in synchronization with a MIDI sequencer. Synchronization
can be accomplished using MTC (MIDI Time Code).
Using MTC (master)
1. Use a MIDI cable to connect the CDX-1 and your MIDI sequencer as shown in
the diagram.
fig.5-27e
2. Press [UTILITY].
The Menu are displayed as icon.
fig.12-06
3. Press CURSOR [ ] to select the MIDI
Parameter icon.
4. Press [YES/ENTER].
The MIDI settings screen appears.
fig.12-07
5. Press CURSOR [ ] to move the cursor to
“Sync Out” line.
MTC (p. 205)
For details on operation of
your MIDI sequencer, refer to
the operating manual for your
device.
Master and slave
When the CDX-1 plays in synchronization with a MIDI sequencer, the device that
transmits the time data is called the master. The device that receives the time data
transmitted by the reference device (master) and follows this data is called the slave.
When playing in synchronization with a MIDI sequencer, the CDX-1 can be
used as the master (transmitting) device, but not as the slave (receiving)
device. Also, the MIDI sequencer must be set as the slave (receiving) device.
MIDI OUTMIDI IN
MIDI Sequencer
CDX-1
To Next Page
