Insert effect algorithm list
1. STEREO MULTI
This algorithm connects seven types of effect, all in full stereo.
Parameter (full name) Setting Function
● COMP (Compressor): Compressor the entire output signals when the input volume exceeds a specified value.
Effect On/Off (Effect On/Off) OFF, ON This parameter turns the compressor effects on/off.
Sustain (Sustain) 0–100 Adjusts the range (time) over which low-level signals are boosted. Larger
values will result in longer sustain.
Attack (Attack) 0–100 Adjusts the strength of the attack. Larger values will result in a sharper
attack, creating a more clearly defined sound.
Level (Output Level) 0–100 Adjusts the volume.
● RNG (Ring Modulator): This creates a bell-like sound. The sound will be unmusical and lack distinctive pitches.
Effect On/Off (Effect On/Off) OFF, ON This parameter turns the ring modulator effect on/off.
Frequency (Frequency) 0–100 This adjusts the frequency of the internal oscillator.
Effect Level (Effect Level) 0–100 This adjusts the volume of the effect sound.
Direct Level (Direct Level) 0–100 This adjusts the volume of the direct sound.
● EQ (Equalizer): A 4-band equalizer.
Effect On/Off (Effect On/Off) OFF, ON This parameter turns the equalizer effect on/off.
Low Gain (Low Gain) -20–+20 dB This parameter sets the gain (amount of boost or cut) for the bass
equalizer.
Low-Mid Gain (Low-Mid Gain) -20–+20 dB This parameter sets the gain (amount of boost or cut) for the low-midrange
equalizer.
Low-Mid Freq (Low-Mid Freq) 100–10.0 kHz This parameter sets the central frequency for the low-midrange equalizer.
Low-Mid Q (Low-Mid Q) 0.5–16 This parameter sets the range of change in gain for the frequency set by
“Low-Mid Freq.” A larger value results in a narrower range of change.
High-Mid Gain (High-Mid Gain) -20–+20 dB This parameter sets the gain (amount of boost or cut) for the high-midrange
equalizer.
High-Mid Freq (High-Mid Freq) 100–10.0 kHz This parameter sets the central frequency for the high-midrange equalizer.
High-Mid Q (High-Mid Q) 0.5–16 This parameter sets the range of change in gain for the frequency set by
“High-Mid Freq.” A larger value results in a narrower range of change.
High Gain (High Gain) -20–+20 dB This parameter sets the gain (amount of boost or cut) for the treble
equalizer.
Level (Output Level) -20–+20 dB This parameter adjusts the volume after the equalizer stage.
Compressor
Ring
Modulator Equalizer
(*1)
Wah
Noise
Suppressor
Chorus
(*2)
Flanger
Pitch Shifter
Phaser
Doubling
Tr emolo/Pan
Delay
*1 Equaliser can be replaced with Wad.
*2 Chorus can be replaced one of the following effects.
