50
Setting How the Strength with Which External
Pads Are Struck Changes the Volume (TRIG CURVE)
With some external pads and acoustic drum triggers, the relationship between the strength with
which you strike the pad and the changes in volume output signal is unnatural. To get natural-
sounding volume changes, set the Trigger Curve.
1
2
Use [ ] or [ ] to select TRIG CURVE.
3
Strike the external pad (or Kick Trigger Unit) to be set.
MEMO
You cannot make settings for the internal pads. If you try to select the internal head by striking it, “---
” is displayed.
TRIG-CURVE EX1H
0
4
Using PATCH/VALUE [+] or [-], set the Trigger Curve (-2, -1, 0, 1, or 2).
Values correspond to the Trigger Curves shown below.
“0” denotes the standard Trigger Curve.
MEMO
To make this setting correctly, set the Trigger Sensitivity before setting the Trigger Curve.
0 (Standard)-2 -1 1 2
Level
Striking Force
Setting the Same Parameter Values to All Pads
For example, with Trigger Type PD-8 set to Trigger Input 1, by pressing [ALL/ENTER], PD-8 is set to all
four Trigger Inputs.
When you press [ALL/ENTER] while in Edit mode, the parameter values that are set in an external pad are
set to all external pads.
In the Edit mode, select the SYSTEM parameter group.
TRIG-CURVE ===
To Next Page
