Configuring the AP
Configuring Ethernet Ports
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 147
Port Type See “Setting Ethernet Port Type” on page 149 for more
detailed information.
•
Trunk port: This port passes all VLAN traffic.
•
Access Port: This port provides network access.
• General Port: User-defined VLAN membership.
Packet Forward
Isolated: Selecting Isolated causes the traffic from this port
to terminate at the AP.
Bridge to WAN: The default setting, Bridge to WAN
forwards packets arriving on this port to the WAN (uplink)
port and eventually to their external destinations using Layer
2 forwarding.
Local Subnet NAT and Route to WAN: This setting
allows routing of packets to their destinations using Layer 3
network address translation (NAT).
Bridge to L2TP Tunnel: Uses Layer 2 Tunneling Protocol
to deliver packets encapsulated with an L2TP header in UDP
datagrams.
Local Subnet This option appears if you have selected Local Subnet and
Route to WAN under Packet Forwarding, and you have
selected Access Port as the port type. This option allows
you to select which subnet this port’s traffic is part of. You
must have previously configured a subnet from the
Configuration > Local Subnets page before it becomes
available here.
Table 50. Configuring Ethernet ports (Continued)
