Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 17
LEDs
Refer to Tabl e 5 for descriptions of LEDs and their behaviors. The LEDs are not
visible once the AP is installed.
4 LEDs See Ta b l e 5 for LED descriptions and behaviors.
Table 5. ZF 7055 LEDs
LED Meaning
PWR
Green: On
Red: Bootup in process
Off: Off
WAN
Green: Link up.
Flashing green: Activity.
Off: Link down.
5G
Off: The WLAN service is down.
Amber: The WLAN is up, but no clients are associated and no downlink MAPs
are connected.
Green: The WLAN is up and at least one client is associated. No downlink
MAPs are connected.
Slow flashing green (one flash every two seconds): The WLAN is up and at
least one downlink MAP is connected. No clients are associated.
Fast flashing green (two flashes every second): The WLAN is up, at least
one downlink MAP is connected, and at least one client is associated.
2.4G
Off: The WLAN service is down.
Amber: The WLAN is up, but no clients are associated and no downlink MAPs
are connected.
Green: The WLAN is up and at least one client is associated. No downlink
MAPs are connected.
Table 4. ZF 7055 rear panel features (Continued)
Number Name Description
