Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 66
ZoneFlex R700 AP
The R700 is a high-capacity, high-performance, three-stream, 802.11ac dual-band
AP with adaptive antenna technology for carriers and enterprises.
NOTE The 100.x AP base images support standalone mode and FlexMaster (FM)
WLAN manager operation. The SmartZone software-compatible images only
support SCG, SZ and vSZ controllers. The ZD-compatible images only support ZD
controllers.
The R700 AP requires a minimum of AP base image 100.0.0 and later to operate,
or SCG 2.1.2 and later, vSZ 2.5 and later, SmartZone software 3.2 and later, or ZD
9.7.1 and later to operate.
The R700 includes five LEDs on its front panel and buttons and connectors on its
rear panel.
Front Panel
Figure 30 shows the top view of the R700. For a description of each front panel
part, refer to Ta bl e 34 .
Figure 30. R700 top view
