Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 43
ZoneFlex 7982 AP
The ZoneFlex 7982 is a high-capacity, high-performing, three-stream AP for carriers
and enterprises.
NOTE The 100.x AP base images support standalone mode and FlexMaster (FM)
WLAN manager operation. The SmartZone software-compatible images only
support SCG, SZ and vSZ controllers. The ZD-compatible images only support ZD
controllers.
The 7982 requires a minimum of AP base image 100.0.0 and later to operate, or
SCG 1.1 and later, vSZ 2.5 and later, SmartZone software 3.2 and later, or ZD 9.4
and later to operate.
The 7982 includes five LEDs on its front panel and buttons and connectors on its
rear panel.
Front Panel
Figure 18 shows the top view of the 7982. For a description of each front panel part,
refer to Ta b le 1 9.
Figure 18. 7982 top view
