Navigating the Web Interface
You manage the AP through a Web browser-based interface that you can access
from any networked computer. Ta bl e 43 lists the Web interface features that are
identified in Figure 52.
Figure 52. Elements of the Ruckus Wireless AP Web Interface
Table 43. Ruckus Wireless AP Web interface elements
No. Element Description
1 Menu Under each category (Status, Configuration, etc.) are options that, when
clicked, open the related workspace in the area to the right.
2 Tabs Contains additional options for the configuration page. For example, the
Configuration > Wireless page includes one tab for common wireless
configuration and eight tabs for each of the available WLANs.
3 LOGOUT Button Click this button to log out of the AP.
4 Help Button Click this button to open a help window with information related
specifically to the options currently displayed in the workspace.
5 Workspace This large area displays features, options and indicators relevant to your
menu bar choices.
