Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 40
Table 17. 7372-E rear panel elements
Number Item Name Description
1 RST Button Pressing, and then quickly releasing this internal button
reboots the AP. Pressing and holding it for six seconds
resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default
settings erases all previously configured settings.
2 10/100/1000+PoE
Port
One RJ-45 port for a 10/100/1000 PoE (Power over
Ethernet, 802.3af) connection.
3 10/100 Port One RJ-45 port for a 10/100 connection.
4 Power Connect the power adapter (12 VDC/1.25A) to this
socket. Power can also be supplied via the 10/100/
1000 PoE port.
5 (two
places)
RP-SMA
connectors
Connect to dual-band 2.4GHz and 5GHz external
antennas.
