Rear Panel
Figure 21 shows the rear view of the H500. For a description of each rear panel part,
refer to Ta b l e 2 3 .
Figure 21. H500 rear view
Table 23. H500 rear panel elements
No. LED Description
1PWR •Off: Off.
• Red: Boot up in process.
• Green: On.
