412VDC
Connect the power adapter (12 VDC/1.25A) to this socket. Power
can also be supplied via the 10/100/1000 PoE port.
Table 30. Behavior of Ethernet port LEDs on the R500
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
Table 29. Rear panel element descriptions (Continued)
No. Label Description
