Installing the AP
Before You Begin
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 79
When wall mounted, the APs should be staggered to maximize coverage.
Figure 35. Recommended wall mounting orientation
Excellent
Reach
Excellent
Reach
Excellent
Reach
Limited
Reach
