To adjust the lens (focus, focal length), use
the adjustment screws. Loosen these
adjustment screws a bit. Move the
adjustment rings to the left/right to get the
best possible picture while observing the
picture quality in the web browser’s live
view.
If you are satisfied with the adjustments,
tighten the adjustment screws again.
Put the inner cover back to the camera
module, respecting the lens position.
Put the dome cover back on.
Screw the two screws on the side of the
dome cover tightly to fasten the dome
cover.
The camera installation is now completed.
