10 Cubis
®
MCE Operating Instructions
Device Description
3 Device Description
3.1 Device Overview
Fig. 1: Precision balance (example)
Pos. Designation Description
1 Manufacturer’s ID label Not depicted
2 Leveling foot Depending on the model: Not adjustable, is screwed
in for leveling.
3 Weighing module
4 Leveling foot Motorically or manually adjustable
5 Control unit
6 Operating display Touchscreen
7 Level
2
1
3
5
4
6
7
