Cubis
®
MCE Operating Instructions 25
Installation
t Carefully pull the connection cable between the control unit and the weighing
module (1) out of the control unit’s retainer and unroll it.
t Turn the device over again and place it on an even surface.
5.5 Preparing Below-cell Weighing
Samples that cannot be placed on the weighing pan can be mounted to the device
base and weighed using the below-cell weighing equipment.
In legal metrology:
− Do not use the below-cell weighing equipment.
− Do not open the cover of the below-cell weighing equipment.
Material: 1 soft support base
Requirements
The weighing pan and all associated components are not placed on the device, e.g.
shield ring, pan support.
Procedure
t Turn over the device and place on a soft surface.
t Remove the hook for below-balance weighing (1) from the retainer on the
underside of the base of the device.
1
1
