Page #61 background imageLoading...
Page #61 background image
Cubis
®
MCE Operating Instructions 61
Technical Data
15.7.3 Models MCE1202S | MCE12201S | MCE8201S | MCE5201S
MCE1202S MCE12201S MCE8201S MC5201S
Unit Value Value Value Value
Scale interval (d)
mg 10 100 100
100
Maximum capacity (Max) g 1200 12200 8200 5200
Repeatability at 5 % load
Standard deviation of the load values,
tolerance
mg 7 50 50 50
Standard deviation of the load values,
typical value
mg 4 20 20 20
Repeatability at approx. maximum capacity
Standard deviation of the load values,
tolerance
mg 7 50 50 50
Standard deviation of the load values,
typical value
mg 4 20 20 20
Linearity deviation
Tolerance mg 20 100 100 100
Typical value mg 6 30 30 20
Deviation when load is off-center, positions
according to OIML R76
Test weight g 500 5000 5000 2000
Tolerance mg 20 200 200 200
Typical value mg 10 100 100 100
Sensitivity drift between +10 °C and +30 °C ppm/K 2 4 4 4
Tare-maximum capacity: Less than 100 % of
maximum capacity
Accuracy class according to Directive 2014/31/EU II II II II
Verification scale interval (e) according to
Directive 2014/31/EU
g 0.1 1 1 1
Minimum load (Min) according to Directive
2014/31/EU
g 0.5 5 5 5
Minimum initial weighing according to USP
(United States Pharmacopeia), Chap. 41
Optimum minimum initial weighing g 8.2 82 82 82
Typical minimum initial weighing g 8.2 82 82 82
Typical stabilization time s 0.8 0.8 0.8 0.8
Typical measurement time s 1 1 1 1
