Sartorius Cubis MCE Series User Manual

60 Cubis
®
MCE Operating Instructions
Technical Data
15.7.2 Models MCE6202S | MCE6202P | MCE4202S | MCE2202S
MCE6202S MCE6202P MCE4202S MC2202S
Unit Value Value Value Value
Scale interval (d)
mg 10 10 | 20 | 50 10
10
Maximum capacity (Max) g 6200 1500 | 3000 |
6200
4200 2200
Repeatability at 5 % load
Standard deviation of the load values,
tolerance
mg 7 7 7 7
Standard deviation of the load values,
typical value
mg 4 4 4 4
Repeatability at approx. maximum capacity
Standard deviation of the load values,
tolerance
mg 7 40 7 7
Standard deviation of the load values,
typical value
mg 4 15 4 4
Linearity deviation
Tolerance mg 20 50 20 20
Typical value mg 6 20 6 6
Deviation when load is off-center, positions
according to OIML R76
Test weight g 2000 2000 2000 1000
Tolerance mg 20 30 30 20
Typical value mg 10 30 10 10
Sensitivity drift between +10 °C and +30 °C ppm/K 2 2 2 2
Tare-maximum capacity: Less than 100 % of
maximum capacity
Accuracy class according to Directive 2014/31/EU II II II II
Verification scale interval (e) according to
Directive 2014/31/EU
g 0.1 0.1 0.1 0.1
Minimum load (Min) according to Directive
2014/31/EU
g 0.5 0.5 0.5 0.5
Minimum initial weighing according to USP
(United States Pharmacopeia), Chap. 41
Optimum minimum initial weighing g 8.2 8.2 8.2 8.2
Typical minimum initial weighing g 8.2 8.2 8.2 8.2
Typical stabilization time s 1 1 1 0.8
Typical measurement time s 1.5 1.5 1 1.5
