10 Entris
®
II Advanced Line Operating Instructions
Operating Concept
4 Operating Concept
4.1 Operating Display
4
1 2 3
5
Fig. 3: Operating display (example)
Pos. Name Description
1 Toolbar
2 Metrological
data
3 Function bar
4 Application
toolbar
 Shows the selected
application.
 Used to access
application-specific
parameters.
5 Main menu Shows the available menus
and applications.
4.2 Weighing Range Display
2
1
4 3
Fig. 4: Weighing range display (example)
Pos. Name Description
1 Measured
value
Displays the current measured
value.
2 User Shows the logged-in user.
3 Bar graph Displays the measured value as
a percentage of weighing
capacity utilization.
4 Time / date
