Entris
®
II Advanced Line Operating Instructions 27
Operating Concept
4.11.14 Parameters in the “Settings / Connections / RS232” Menu
Parameters Settings Explanation
Device /
Protocol
SBI Defines the connected device or the interface protocol.
xBPI
Printer YDP20
Printer YDP30
Second
display
Barcode
reader
Off
RS232
configuration
Baudrate Configures the RS232 interface.
Data bits
Parity
Handshake
Foot switch
function
Print If a foot switch is connected: Sets the function that is triggered by pressing the
foot switch.
End
application
Run
application
Zero
Tare
Leveling
End of ISO /
GLP
Off
