ii. Basic Layout
Insert SD Card
Lanyard Point
Lanyard Point
SiRF III GPS
GPS Lock Icon
SiRF III GPS
Trail Taken
Location Icon
Mini USB
9 Function
Joystick
Large Side/Front
Multifunction Keys
Side/front press
keys e
nable one-
handed operation.
Buttons are variable
(depending on the
screen shown)
and can be set to
activate with 1-click
or 2-click operation .
Backlight Boost
Toggle Map Icon
Battery Indicator
On/Off
Planning Icon
Replaceable
Screen Cover
3.5 in / 8.7cm
Bright, Hi-Res
HVGA (320x480)
Screen
Weatherproof,
Toughened
Impact Casing
Lock/
Unlock
Screen 3.4 in / 8.7cm
Width 3 in / 7.5cm
Height 5.1 in / 13cm
Depth 1.4 in / 3.5cm
Weight 6.2 oz / 175g
Removable
Battery Back
Can be replaced
with a Battery
Back for
mounting on a
bike or in a car,
or with a Slimline
Battery Back for
a lighter unit with
a lower profile.
Stats Recording
Bluetooth Icon
