Section 2: General Specifications
CG4 Series Service Manual Page 2-1
GENERAL SPECIFICATIONS
2.1 PRINTER BASIC SPECIFICATIONS
MODEL NAME
CG408 DT CG412 DT CG408 TT CG412 TT
PHYSICAL CHARACTERISTICS
Width 179 mm (7.05”)
Depth 238 mm (9.37”)
Height 173 mm (6.81”)
Weight 1.7 kg (3.7 lbs.) 1.9 kg (4.19 lbs.)
POWER SUPPLY (AC ADAPTER)
Input Voltage 100-240 V AC, +/-10%, 50/60 Hz (Full range)
Output Voltage 19 V DC, +/-5%, 3.86A
Power Consumption
At peak times: 50 Watts
During standby: 2.5 Watts
ENVIRONMENTAL (EXCLUDING MEDIA)
Operating Temperature 4° to 38°C (39.2 to 100.4°F)
Storage Temperature -10° to 60°C (14 to 140°F)
Operating Humidity 30 to 80% RH, Non-condensing
Storage Humidity 15 to 85% RH, Non-condensing
PRINT
Method DT models: Direct Thermal only
TT models: Thermal Transfer and Direct
Thermal
Print Speed (selectable)
50, 75 or 100 mm/second
2, 3 or 4 Inches/second (Setting: 2, 3, 4)
*Maximum print speed varies depending on the of media used.
Resolution
8 dots/mm (203
Dots Per Inch)
12 dots/mm (305
Dots Per Inch)
8 dots/mm (203
Dots Per Inch)
12 dots/mm (305
Dots Per Inch)
Maximum Print Width 104 mm (4.09”)
Maximum Print Length 300 mm (11.81”)
