SATO CG4 Series Service Manual

Section 2: General Specifications
CG4 Series Service Manual Page 2-7
2.2 OPTIONAL ACCESSORIES SPECIFICATIONS
CUTTER SPECIFICATIONS
Media Type Non-adhesive paper and Label
Media Size
Pitch : 22 to 300 mm (0.87” to 11.8”)
Pitch including liner : 25 to 303 mm (0.98” to 11.93”)
Width : 22 to 107 mm (0.87” to 4.21”)
Width including liner : 25 to 110 mm (0.98” to 4.33”)
Thickness 0.06 to 0.19 mm (0.0024” to 0.0074”)
Self-diagnosis function Cutter error detection
Durability More than 300,000 cuts
DISPENSER SPECIFICATIONS
Media Type
Label only
* Some restrictions may apply to some label types depending on the substrate,
adhesive, paper size, and environment. Refer to SATO representative on the
labels to be used.
* Perforated liner and split liner cannot be used.
* Peel end labels
Media Size
Pitch : 22 to 100 mm (0.86” to 3.93”)
Pitch including liner : 25 to 103 mm (0.98” to 4.05”)
Width : 22 to 107 mm (0.86” to 4.21”)
Width including liner : 25 to 110 mm (0.98” to 4.33”)
Thickness 0.06 to 0.19 mm (0.0024” to 0.0074”)
Sensor Type Dispenser sensor (Reflective type)
LINERLESS (NONSEPA) KIT SPECIFICATIONS
Media Type Micro-perforated Linerless (Nonesepa) Label
Media Size
Pitch : 25 to 100 mm (0.98” to 3.93”)
With : 25 to 110 mm (0.98” to 4.33”)
Thickness 0.06 to 0.19 mm (0.0024” to 0.0074”)
Media Winding direction Face-out
Roll and core Diameter Maximum outer diameter: 128 mm (5.04”) with Inner core diameter: 40 mm (1.5”)
Sensor Type Label sensor (Reflective type)
Label issuing mode Continuous mode, Tear-off mode
