Section 8: Appendix
CG4 Series Service Manual Page 8-15
8.8 PAPER END
8.8.1 Roll Label End
When the Label End is less than 40mm (1.57”) from the end of I-Mark
The printer behavior when paper end is detected is as follows:
• After completing the print of label (1), “Paper end error” will occur.
• In cutter mode, “Paper end error” will occur after cutting the label.
• After releasing the error, Label (1) will not be printed again.
Note:
The paper end detection is performed by the I-Mark sensor, therefore, the above motion may not occur
depending on the adjustment of the I-Mark sensor.
When the Label End is More Than 40mm (1.57”) from the end of I-Mark
The printer behavior when paper end is detected is as follows:
• “Paper end error” will occur while printing the label (2).
• If an error occurs while printing, label (2) will be printed again after releasing the error. If the print job is
completed at the time of error occurrence, label (2) will not be printed again.
• In cutter mode, cutting motion will not occur when the printer has a “Paper end error.”
Note:
The paper end detection is performed by the I-Mark sensor, therefore, the above motion may not occur
depending on the adjustment of the I-Mark sensor.
