SATO CG4 Series Service Manual

Section 4: Operation and Configuration
Page 4-30
CG4 Series Service Manual
4.16 PRINTER CONFIGURATIONS SETTING
You can set the printer configuration by sending SBPL commands from the host computer or by using the
Utilities Tool application provided (SATO Accessory CD-ROM).
No. Category Setting item Setting contents
1 Operation mode Print method
(CG408TT/ CG412TT
printer only)
Thermal Transfer/ Direct Thermal
2 Print speed 50mm/s to 100mm/s
3 Print mode Continuous/ Tear Off/ Cutter/ Dispenser/
Nonesepa (Linerless)
4 Cutter mode Head position/ Cut position/ No backfeed
5 Dispenser mode Head position/ Dispense position
6 Nonesepa mode Tear Off position/ No backfeed
7 Print darkness A
8 Print darkness level 1 to 5
9 Sensor type I-Mark/Gap/Sensor-off/Transmissive (CX com-
patible)
10 Zero slash Disabled/ Enabled
11 Kanji code JIS code/SJIS code
12 Initial feed Disabled/ Enabled
13 Character pitch Fixed/ Proportional
13 Option Waiting time 5 to 200 (x100ms)
14 Media size Pitch 1 to 2400 dots (including liner/backing paper)
[CG408TT/DT]
1 to 3600 dots (including liner/backing paper)
[CG412TT/DT]
15 Width 1 to 832 dots (including liner/backing paper)
[CG408TT/DT]
1 to 1248 dots (including liner/backing paper)
[CG412TT/DT]
16 Base reference
point
Vertical print position
offset
±792dot
17 Horizontal print posi-
tion offset
±792dot
18 Offset setting Continuous mode ±99dot
19 Tear Off mode ±99dot
20 Cutter mode ±99dot
21 Dispenser mode ±99dot
