SATO CG4 Series Service Manual

Section 4: Operation and Configuration
CG4 Series Service Manual Page 4-11
4.4 FACTORY TEST PRINT MODE (cont’d)
4.4.1 Output Data of the Factory Test Print
The output data of the Factory Test Print shows the internal operating parameters of the printer.
These output data are printed in three parts, each with the printing area of 110mm [4.33”] (Width) x 115mm
[4.53”] (Pitch), Standard.
First print-out (Settings)
No. Print Item Contents of the print data
1 Model Printer model name CG408TT(*), CG412TT(*)
CG408DT, CG412DT
*: “T” is printed for thermal
transfer print.
“D” is printed for direct
thermal print.
2 Firm Ver Printer F/W version **.**.**.**
3 Firm Date Printer F/W creation date YY.MM.DD
4 Font Version Font version **.**
5 Serial No. Serial No. Serial No./ None
6 Life Counter Life counter *.* Km
7 Head Counter1 Head counter 1 *.* Km
8 Head Counter2 Head counter 2 *.* Km
9 Head Counter3 Head counter 3 *.* Km
10 Cutter Counter Cutter counter *
11 Thermistor Print head temperature 0 to 255
12 Sensor Type Sensor type Gap
I-Mark
None
13 Sensor Level Low Average minimum value of
pitch sensor
*.* V
14 Sensor Level High Average maximum value of
pitch sensor
*.* V
15 Sensor Slice Level Pitch sensor slice level *.* V
16 FROM CHECK SUM Printer F/W: Font: Check
sum
(A)****
(B)****
(P)****
17 Sensor Out Level I-mark I-Mark level *
18 Sensor Out Level Gap Gap level *
