sauter Equitherm - 2 Description of the Operating Controls; Front View of the EQJW 145; Fig. 1: EQJW 145 - Front View

EQJW145:
Heating controller
Description
of the operating controls
7010015003 A
11
© Fr. Sauter AG
2 Description of the operating controls
2.1 Front view of the EQJW 145
1
2
3
4
°C
sec
1
h
Fig. 1: EQJW 145 - Front view
Rotary switch
Display
ESC button
Input knob
The device has a rotary switch with 10 positions, an input knob and a button.
1
2
3
4
