EQJW145:
Heating controller
Resistance
values for the Ni1000 sensors
7010015003 A
91
© Fr. Sauter AG
10 Resistance values for the Ni1000 sensors
The temperature sensors required depending on the use of the EQJW 125
must conform to DIN 43760.
Temperature (°C) Resistance value (
) Ni1000
90 1549
80 1483
70 1417
60 1353
50 1291
40 1230
30 1171
20 1112
10 1056
0 1000
–10 946
–20 893
–30 842
–40 791
Tab. 11: Resistance value Ni1000
The resistance value of the nickel measuring resistor changes in relation to
the temperature. The temperature coefficient is always positive, i.e. the
resistance increases as the temperature rises. See the table of values
(DIN 43760). Within the specified tolerances, the sensors can be exchanged
without calibration.
