sauter Equitherm - List of Communication Parameters

EQJW145:
Heating controller
Commissioning
40 7010015003 A
© Fr. Sauter AG
3.4.4 List of communication parameters
Parameter Description Range Step-
value
CP01 Internal serial number of EQJW 145 (read only) –
CP02 2 Type of communication

0 = no communication

1 = device bus

2 = MOD bus via RS485

3 = MOD bus via modem

4 = SMS via modem

5 = MOD Bus and SMS via Modem
0…5 1
CP03 19200 Baud rate 9600, 19200 –
CP04 – Device bus: address EQJW 145 1…32, auto 1
CP05 – MOD bus via RS485: address EQJW 145 1…247 1
CP06 – MOD bus via modem: phone number of the control station – 1
CP07 – SMS via modem: telephone number of the provider (TAP protocol) – 1
CP08 – SMS via modem: telephone number of the mobile phone – 1
CP09 0 Device bus: time synchronisation

0 = not enabled. 1 = enabled
0…1 1
CP10 0 Device bus: send outdoor temperature

0 = not enabled. 1 = enabled
0…1 1
CP11 0 Device bus: receive outdoor temperature

0 = not enabled. 1 = enabled
0…1 1
CP12 0
Device bus: send heat requirement (T
F
)

0 = not enabled. 1 = enabled
0…1 1
CP13 0
Device bus: receive heat requirement (T
F
)

0 = not enabled. 1 = enabled
0…1 1
CP14 0 Device bus: send return temperature

0 = not enabled. 1 = enabled
0…1 1
CP15 0

Device bus: receive return temperature
0 = not enabled. 1 = enabled
0…1 1
CP16 0 Device bus: send error

0 = not enabled. 1 = enabled
0…1 1
CP17 0

Device bus: receive error
0 = not enabled. 1 = enabled
0…1 1
CP18 0 Device bus: EDB 100 digital room operating unit

0 = EDB 100 not connected,

1 = EDB 100 connected
0…1 1
