sauter Equitherm - Modbus Data Points (Coils)

EQJW145:
Heating controller
C
ommunication functions
74 7010015003 A
© Fr. Sauter AG
6.3.2 Modbus data points (coils)
Coil no. Description Comment Can be
set?
Can be
deleted?
0 1
4 Collective level bit Controller controls all functions
independently of the control station
yes no BMS AUTONO
MOUS
32 Binary input, Cl. 22 Binary input, Cl. 22/Cl. 21 no no OPEN CLOSED
57 Binary output term.
6
Relay output terminal 6 = UP (->CL96) yes yes OPEN CLOSED
60 Binary output term.
7
Relay output terminal 7 (->CL99) yes yes OPEN CLOSED
64 Binary output term.
8
Relay output terminal 8 (->CL100) yes yes OPEN CLOSED
61 Binary output term.
10
Relay output terminal 10 (->CL97) yes yes OPEN CLOSED
88 EBN AF1 Controller measures outdoor
temperature (HR40010) itself
yes no BMS AUTONO
MOUS
89 EBN Mode Rk1 Controller switches mode (HR40106)
itself
yes no BMS AUTONO
MOUS
90 EBN control sig.
Rk1
Controller controls control signal Rk1
(HR40107) itself
yes no BMS AUTONO
MOUS
96 EBN Binary term. 6 Controller switches heating medium
pump UP1 (CL57) itself
yes no BMS AUTONO
MOUS
97 EBN Binary term. 10 Controller switches term. 10 (CL61)
itself
yes no BMS AUTONO
MOUS
99 EBN Binary term. 7 Controller switches term. 7 (CL60)
itself
yes no BMS AUTONO
MOUS
100 EBN Binary term. 8 Controller switches term. 8 (CL64)
itself
yes no BMS AUTONO
MOUS
116 EBN FlowSetpoint
Rk1
Controller determines flow setpoint for
Rk1 (HR41000) itself
yes no BMS AUTONO
MOUS
150 DisableManual Release manual levels yes yes INACTIV
E
ACTIVE
157 DisableModem Disable dialling to BMS yes yes INACTIV
E
ACTIVE
158 Dial going BMS dialling also with faults present yes yes INACTIV
E
ACTIVE
