EQJW145:
Heating controller
Operation
7010015003 A
49
© Fr. Sauter AG
4. The current actual value for the room
temperature (only if a room sensor is present).
•
The flow setpoint (not available in OFF
mode or summer mode, for example).
•
The current actual value for the flow
temperature.
•
The outdoor temperature that is currently
measured.
•
Then you will see the DHW setpoint
(if DHW preparation has been configured),
•
The current measured DHW temperature
(if DHW preparation has been configured).
5. Turn the knob further in a clockwise direction
to display the time again.
You can also turn the knob in the opposite direction to scroll backwards
through the displays. In some cases, more displays can be added to the
display loop, e.g.
Show setpoint and actual value for return temperature
The display (see 7), can be added in case of a fault A display of the
connection status can be added for modem operation (see 6.4)
Press the ESC button once to go directly to the time display.
