EQJW145:
Heating controller
Communication
functions
7010015003 A
71
© Fr. Sauter AG
Number of
holding
register
Description Comment Read
only
Decimal
points
Units
With math.
Sign?
40108 Mode_Rk2 1=Auto, 2=Stdby, 3=Manual, 4=Sun,
5=Moon
no 0 no
40109 ControlSignal_Rk2 Opening for control signal Rk2
[0...100%]
no 0 % no
40117 AT_HeatOff_Rk1
Value T
A
heating switch-off
no 1 °C yes
40145 Write-En_Modem Write enable for modem
(code number input)
no 0 no
40146 Cycl_Init_Modem Modem - cyclical initialisation no 0 min no
40147 DialPause_Modem Modem - dialling pause after engaged
tone
no 0 min no
40148 DialRpt_Modem Modem - number of dialling attempts no 0 no
40149 Timeout_Modem Watchdog, 'Modem time constant' no 0 min no
40150 Device statusReg Device status register yes 0 no
40152 ErrorstatArchiv Device status archive no 0 no
40154 ErrorCounterReg Error counter register no 0 no
41000 FlowSetp_Rk1 Flow setpoint no 1 °C yes
41001 MaxFlow_Rk1 Maximum flow temperature no 1 °C yes
41002 MinFlow_Rk1 Minimum flow temperature no 1 °C yes
41003 Day_Setp_Rk1 Setpoint - normal mode no 1 °C yes
41004 Night_Setp_Rk1 Setpoint - reduced mode no 1 °C yes
41006 Slope_HeatCh_Rk1 Slope of heating characteristic no 1 no
41065 Kp_Rk1 Proportional band no 1 no
41066 Tn_Rk1 Reset time no 0 sec no
41067 Ty_Rk1 Running time for actuator no 0 sec no
41800 WW setpoint increased Setpoint WW for thermal disinfection
(20°C…90°C)
no 1 °C no
41807 WW setpoint normal Setpoint WW in normal case
(20°C…90°C)
no 1 °C no
41865 Kp_Rk2 Proportional band (2nd heating circuit) no 1 no
41866 Tn_Rk2 Reset time (2nd heating circuit) no 0 sec no
41867 Ty_Rk2 Running time for actuator (2nd heating
circuit)
no 0 sec no
