Scania DC11 - Page 70

70
©
Scania CV AB 2011, Sweden
01:03-02
16 Remove the press drift by detaching flange
nut 8 and pushing in the threaded stem.
Note: The races for camshaft bearing numbers
2, 4 and 6 have two oil ways. The others only
have the lower one.
17 Check that the bearing oil hole is central to
the cylinder block oil ways.
18 Repeat the procedure for the remaining
bearings.
Pressing out/pressing in bearing number 2.
Check measurement of bearing number 2.
19 Clean the sealing surface, take a new gasket
and fit the blanking piece for the camshaft at
the front of the engine.
20 Refit the camshaft according to the section
Fitting the Camshaft. Then check the
camshaft setting.
Cylinder block
