82
©
Scania CV AB 2011, Sweden
01:03-02
4 Prise off the sealing ring using a
screwdriver. Take care not to damage the
sealing surface in the housing.
5 Wipe clean the sealing ring seat in the
housing.
Note: The crankshaft seal must be fitted dry and
must not be lubricated. The sleeve in the seal
must not be removed until just before the
crankshaft seal is to be fitted on the engine.
6 Place the new seal in tool 99 374 and press
it into place by tightening the bolts
alternately. The seal is correctly fitted when
the tool reaches the bottom.
The seal is correctly fitted when the tool reaches
the bottom.
7 Remove the tool. Fit the bolts into the
threaded holes and use as a handle to make
removal easier.
8 Wipe clean the sealing surface on the pulley
and fit it immediately.
9 Fit the fan belt.
10 Fit the fan and fan ring.
11 Refit the radiator according to the
description in Group 02, Cooling system.
Front crankshaft seal
