Note: Monitor service value “Belt Drift Tr” indicating
the deviation of mid sensor and thus of belt from
sensor position in cm.
Example: Belt drift = 0.20 cm: Parameter N08
“Sensor Offset” = - 0.20 cm indicates belt slip 0.00 cm.
8. If necessary, determine event classes of belt slip
and drift messages (Parameters N09...N17).
Note: Normally, the default values can be used
in actual practice.
9. Check messages.
Note: To check, adapt Parameter N08
“SensorOffset” accordingly and remember to
reset value to default.
Belt Influence Compensation BIC
The automatic Belt Influence Compensation BIC is
designed to monitor and correct the belt influence. As
is with belt run monitoring, a sensor and a sensor area
are required. To commission BIC, first start belt run
monitoring.
Note: Perform initial commissioning without active
BIC.
Features
After start of the belt influence compensation, the
influence of the conveyor belt on measurement will be
compensated after approx. 10 belt circuits.
Prerequisites:
·
Belt run monitoring commissioned
·
Belt run monitoring started.
To start BIC, set Parameter N05 “BIC Active” to “YES”
.
Control for Point of Discharge CPD
Upon measurement at the point of discharge, the
measuring point of the weighing platform is shifted to
the point of material discharge using a delay element.
The amount discharged is measured direct.
Note: If CPD is active, Automatic Belt Influence
Compensation BIC should be started as well.
Prerequisites:
·
Length ratio from mid platform to material discharge
point and total conveyor belt length is known.
·
Length ratio in percent is entered into Parameter
N02 “Platf.Dis.Length”.
To start CPD, set Parameter N01 “CPD Active” to
“YES” .
0837
VBW INTECONT PLUS
Commissioning
BV-H2214 GB 92
Technische
Redaktion PDE-RD
Transmission to third parties and reproduction of
this documentation are not permitted. Schenck
Process GmbH reserves all rights of ownership
and copyrights.
