Maximum H
H1 : I > MAX
Current feed rate exceeds set limit value.
Action : Normally none, unless
message H4 is available or
system-specific limits have to
be observed.
Parameters : F 03, F 04
H2 : Load > MAX
Current belt load exceeds set limit value.
Action : Normally none, unless
message H4 is available or
system-specific limits have to
be observed.
Parameters : F 07, F 08
H3 : v > MAX
Current belt load exceeds set limit value.
Action : System specific unless C2 is
additionally available.
Parameters : F 11, F 12
H4 : L/C Input > MAX
Weighing system overloaded. Errors in
measurement possible.
Action : Check material infeed; belt
load is too big.
Parameter : O 08
Minimum L
L1 : I < MIN
Current feed rate has fallen below set limit
value. Error in measurement possibly out of
tolerance.
Action : System specific unless L4 is
additionally available
Parameters : F 01, F 02
L2 : Load < MIN
Current belt load has fallen below set limit
value.
Action : See L1
Parameters : F 05, F 06
L3 : V < MIN
Current belt speed has fallen below set limit
value.
Action : Check to see if belt is running.
Parameters : F 09, F 10
L4 : L/C Input < MIN
Weighing system underloaded. Errors in
measurement possible.
Action : Check mechanical weighing
system, weighed idler
alignment and load cell cable.
Parameter : O 09
0837
INTECONT PLUS VBW
Event Messages
BV-H2214 GB 87
